| Interfata |
- 8× Porturi RJ45 100/1000/2500 Mbps
- 2× Sloturi 10G SFP+
- 1× Port RJ45 pe consola
- 1× Port Micro-USB pe consola
|
| Numar ventilatoare |
2 |
| Alimentator |
100-240 V AC~50/60 Hz |
| Porturi (RJ45) PoE |
- Standard: 802.3at/af compliant
- Porturi PoE+: 8 porturi
- PoE Power Budget: 240 W*
|
| Dimensiuni |
440 × 180 × 44 mm |
| Montaj |
in rack |
| Consum maxim |
- V1: 17.24 W (110V/60Hz) (fara PD conectat)
- 291.49 W (110V/60Hz) (cu PD 240 W conectat)
- V2: 291.49 W (110V/60Hz) (cu PD 240 W conectat)
|
| Disipare caldura |
- V1: 58.82 BTU/h (110 V/60 Hz) (fara PD conectat)
- 994.56 BTU/h (110 V/60 Hz) (cu PD 240 W conectat)
- V2: 996.35 BTU/hr (110 V/60 Hz) (cu PD 240 W conectat)
|
| Performanta |
|
| Capacitate |
80 Gbps |
| Viteza pachete |
59.52 Mpps |
| Tabela Adrese MAC |
16 K |
| Packet Buffer Memory |
12 Mbit |
| Jumbo Frame |
9 KB |
| Caracteristici Software |
|
| Calitatea Serviciului |
- 8 porturi prioritare
- 802.1p CoS/DSCP
- Programare
- SP (Strict Priority)
- WRR (Weighted Round Robin)
- SP+WRR
- Control latime banda
- Action for Flows
- Mirror (pentru interfetele suportate)
- Redirect (pentru interfete suportate)
- Rate Limit
- QoS Remark
|
| Caracteristici L3 |
- 16 Interfete IPv4/IPv6
- Static Routing
- Static ARP
- Proxy ARP
- Gratuitous ARP
- DHCP Server
- DHCP Relay
- DHCP Interface Relay
- DHCP VLAN Relay
- DHCP L2 Relay
|
| Caracteristici L2 si L2+ |
- Link Aggregation
- static link aggregation
- 802.3ad LACP
- Up to 8 aggregation groups, containing 8 ports per group
- Spanning Tree Protocol
- 802.1d STP
- 802.1w RSTP
- 802.1s MSTP
- STP Security: TC Protect, BPDU Filter, Root Protect
- Loopback Detection
- Flow Control
- 802.3x Flow Control
- HOL Blocking Prevention
- Mirroring
- Port Mirroring
- CPU Mirroring
- One-to-One
- Many-to-One
- Tx/Rx/Both
|
| L2 Multicast |
- IGMP Snooping
- IGMP v1/v2/v3 Snooping
- Fast Leave
- IGMP Snooping Querier
- IGMP Authentication
- MLD Snooping
- MLD v1/v2 Snooping
- Fast Leave
- MLD Snooping Querier
- Static Group Config
- Limited IP Multicast
- MVR
- Multicast Filtering: 256 profiles and 16 entries per profile
|
| Caracteristici Avansate |
- Automatic Device Discovery
- Batch Configuration
- Batch Firmware Upgrading
- Intelligent Network Monitoring
- Abnormal Event Warnings
- Unified Configuration
- Reboot Schedule
|
| VLAN |
- VLAN Group
- 802.1Q Tagged VLAN
- MAC VLAN: 10 Entries
- Protocol VLAN: Protocol Template 16, Protocol VLAN 16
- Private VLAN
- GVRP
- VLAN VPN (QinQ)
- Port-Based QinQ
- Selective QinQ
- Voice VLAN
|
| Lista Control Acces |
- Time-based ACL
- MAC ACL
- Source MAC
- Destination MAC
- VLAN ID
- User Priority
- Ether Type
- IP ACL
- Source IP
- Destination IP
- Fragment
- IP Protocol
- TCP Flag
- TCP/UDP Port
- DSCP/IP TOS
- User Priority
- Combined ACL
- Packet Content ACL
- IPv6 ACL
- Policy
- Mirroring
- Redirect
- Rate Limit
- QoS Remark
- ACL apply to Port/VLAN
|
| Securitate |
- IP-MAC-Port Binding
- DHCP Snooping
- ARP Inspection
- IPv4 Source Guard: 100 Entries
- IPv6-MAC-Port Binding
- 512 Entries
- DHCPv6 Snooping
- ND Detection
- IPv6 Source Guard: 100 Entries
- DoS Defend
- Static/Dynamic Port Security
- Up to 64 MAC addresses per port
- Broadcast/Multicast/Unicast Storm Control
- 802.1X
- Port base authentication
- Mac base authentication
- VLAN Assignment
- MAB
- Guest VLAN
- Support Radius authentication and accountability
- AAA (including TACACS+)
- Port Isolation
- Secure web management through HTTPS with SSLv3/TLS 1.2
- Secure Command Line Interface (CLI) management with SSHv1/SSHv2
- IP/Port/MAC based access control
|
| Management |
- Omada App: Da (Prin OC300, OC200, Omada Cloud-Based Controller sau Omada Software Controller)
- Centralized Management
- Omada Cloud-Based Controller
- Omada Hardware Controller (OC300)
- Omada Hardware Controller (OC200)
- Omada Software Controller
- Cloud Access: Da (Prin OC300, OC200, Omada Cloud-Based Controller sau Omada Software Controller)
- Zero-Touch Provisioning: Da. Necesita utilizarea Omada Cloud-Based Controller.
- Management Features
- Web-based GUI
- Command Line Interface (CLI) through the console port, telnet
- SNMP v1/v2c/v3
- Trap/Inform
- RMON (1,2,3,9 groups)
- SDM Template
- DHCP/BOOTP Client
- 802.1ab LLDP/LLDP-MED
- DHCP AutoInstall
- Dual Image, Dual Configuration
- CPU Monitoring
- Cable Diagnostics
- EEE
- Password Recovery
- SNTP
- System Log
|
| ALTELE |
- Certificari: CE, FCC, RoHS
- Cerinte de sistem: Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ sau Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® sau Linux.
- Mediu
- Temperatura de operare: 0–50 ℃
- Umiditate mediu operare: 10–90% RH fara condens
|
