Descriere

• Standard WLAN: IEEE 802.11 a/n/ac
• Mod radio: MIMO 2×2
• Banda de frecventa radio: 5.150 – 5.850 GHz (FCC 5.150 – 5.250 and 5.725 – 5.850 GHz)
• Putere de transmisie: max 30 dBm
• Sensibilitate de receptie: -97 ~ -75 dBm (in functie de modulatie)
• Dimensiune canal: 5, 10, 20, 40, 80 MHz
• Schema modulare: 802.11 a/n: OFDM (64-QAM, 16-QAM, QPSK, BPSK), 802.11 ac: OFDM (256-QAM, 64-QAM, 16-QAM, QPSK, BPSK)
• Viteza de comunicatie: 802.11 ac @ 40 MHz: 400, 360, 300, 270, 240, 180, 120, 90, 60, 30 Mbps/ 802.11 ac @ 80 MHz: 866, 780, 650, 585, 520, 390,260, 195, 130, 65 Mbps
• Corectarea erorii: FEC, LDPC
• Duplex de divizare a timpului
• Distanta de transmisie: 0 – 3 km recomandat, max 5 km
• Interfata: 10/100/1000 Base-T, RJ45
• Mod de operare wireless: acces point (auto WDS), acces point (TDMA), station (WDS, TDMA), station (ARP NAT)
• Tehnici wireless: smart station polling, smart auto-channel, auto-modulatie adaptiva, control automat al puterii de transmisie (ATPC)
• Securitate wireless: WPA/WPA2 personal, WPA/WPA2 enterprise, WACL, user isolation
• QoS wireless: prioritizare 4 siruri la TDMA
• Mod de operare a retelei: bridge, router iPv4, router IPv6
• Tehnici de retea: routing cu si fara NAT, VLAN
• Protocol WAN: static IP, DHCP client, PPPoE client
• Servicii: server DHCP, server SNMP, client NTP, daemon reclama router, ping watchdog
• Management: HTTP(S) GUI, SSH, SNMP read, Telnet
• Monitorizare sistem: SNMP, Syslogs, WEB UI, DWMP
• Unelte: Site Survey, Link Test, antena alignment
• Raza de frecventa antena: 5.1 – 5.9 GHz
• Gain: 15 dBi
• Polarizare: dual linear
• Izolare transversala: 21 dBi
• VSWR: <1.4
• Grad protectie: IP66
• Montaj: stalp
• Alimentare: 12 – 24 VDC pasiv PoE
• Sursa de alimentare: 100 – 240 V AC
• Consum de putere: 10 W
• Temperatura de functionare: -30°C – 70°C
• Umiditate: 0-90% fara condens
• Dimensiune: 128 x 97 x 40 mm
• Greutate: 200 g
