Descriere
| Interfata: | 5 porturi 10/100/1000 Mbps RJ45, Auto-Negociere, Auto-MDI/MDIX |
| Standarde: | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p |
| Retea media: | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m), 100BASE-TX: UTP category 5, 5e cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m), 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m) |
| Numar ventilatoare: | Fara ventilatoare |
| Disipare termica maxima: | 9.07 BTU/h |
| Rata de expediere a pachetelor de date: | 7.44 Mpps |
| Tabela Adrese MAC: | 2000 |
| Pachete memorie buffer: | 1.5 MB |
| Jumbo Frame: | 16 KB |
| Calitatea serviciului: | Suporta prioritate Port-based/802.1p/DSCP, Suporta prioritate 4 cozi, Rate Limit, Storm Control |
| Caracteristici L2: | Spionaj IGMP V1/V2/V3, Agregare Static Link, Port Mirroring, Diagnosticare prin cablu, Prevenirea buclelor |
| VLAN: | Suporta simultan pana la 32 VLAN-uri, MTU/Port/Tag VLAN |
| Metoda de Transmisie: | Store & Forward |
| Consum energie: | 2.66 W |
| Alimentare: | 90V DC / 0.6 A |
| Dimeniuni: | 100 x 98 x 25 mm |
| Temperatura de functionare: | 0°C – +40°C |
| Umiditate: | 10 % – 90 % RH |
