Stoc epuizat
| General | |
|---|---|
| Interfata: | 6x porturi RJ45 10/100/1000 Mbps, 2x sloturi combo Gigabit RJ45/SFP |
| Standarde port: | IEEE 802.3i:10BASE-T Ethernet, IEEE 802.3u:100BASE-X Fast Ethernet, IEEE 802.3ab:1000BASE-T Gigabit Ethernet, IEEE 802.3z:1000BASE-X Gigabit Ethernet (Fibra optica), IEEE 802.3x: Flow Control, IEEE 802.1p: Traffic Class Expediting si Dynamic Multicast Filtering, IEEE 802.1q: VLAN, IEEE 802.1d: STP, IEEE 802.1w: RSTP, IEEE 802.1ab: LLDP |
| Performanta | |
| Capacitate de comutare: | 16 Gbps |
| Rata de redirectionare pachete: | 11.9 Mpps |
| Tabela adrese MAC: | 8K |
| Memorie buffer pachete: | 4 Mbit |
| Jumbo Frame: | 15 KB |
| Metoda de transmisie: | Store-and-Forward |
| Alimentare si protectii | |
| Alimentare: | 9.6-60 V, intrare DC dual-redundanta |
| Protectie curent si tensiune: | Suprasarcina curent, supratensiune, protectie polaritate inversa |
| Consum standby: | 1.79 W @12 VDC, 2.16 W @24 VDC, 3.17 W @48 VDC |
| Consum maxim: | 4.46 W @12 VDC, 4.17 W @24 VDC, 5.99 W @48 VDC |
| Relé fault: | 24 V / 1 A max., contact normal inchis |
| MTBF: | 863,865 ore @ 25°C |
| Dimensiuni (L×l ×H): | 129 × 95 × 45 mm |
| Numar ventilatoare: | Fanless |
| Montaj: | Montare pe sina DIN si montare pe perete |
| Grad de protectie: | IP40 |
| Temperatura de functionare: | de la -40°C pana la 75°C |
| Umiditate operare: | 5%-95% RH |
| Protectie supratensiune: | ±6 kV pentru porturi Ethernet, ±4 kV pentru alimentare DC |
| Protectie ESD: | Aer ±8 kV, Contact ±6 kV |
| Certificari: | CE, FCC, RoHS |
| L2 Features si VLAN | |
| Link Aggregation: | Static, pana la 2 grupuri si 4 porturi per grup |
| Loopback Detection: | Da |
| Flow Control: | 802.3x Flow Control |
| Mirroring: | Port Mirroring, One-to-One, Many-to-One, Ingress/Egress/Both |
| Port Statistics: | Status Port Mirror, Traffic Statistics |
| LLDP: | 802.1ab |
| Spanning Tree: | STP (802.1d), RSTP (802.1w) |
| Multicast L2: | IGMP Snooping v1/v2/v3, Fast Leave |
| VLAN: | MTU VLAN, Port-Based VLAN, 802.1Q Tag VLAN, max 32 grupuri VLAN, 4K VID |
| QoS | |
| Quality of Service: | 802.1p DSCP Priority, 8 cozi de prioritate, mod WRR, configurare greutate cozi, control latime de banda pe port, Storm Control broadcast/multicast/unknown-unicast |
| Management | |
| Management: | Web GUI, client DHCP, diagnostic cablu, Digital Diagnostic Monitoring (DDM), suport SDN cu Hardware/Software/Cloud Controller, descoperire automata, configurare batch, upgrade firmware batch, configurare unificata |
