Descriere

• Interfata: 24 de porturi RJ45 10/100/1000 Mbps, Auto-Negociere, Auto-MDI/MDIX
• Standarde: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
• Retea media: 10BASE-T – Cablu UTP categoria 3, 4, 5 (max. 100 m), EIA/TIA-568 100Ω STP (max. 100 m), 100BASE-TX – Cablu UTP categoria 5, 5e (max. 100 m), EIA/TIA-568 100Ω STP (max. 100 m), 1000BASE-T – Cablu UTP categoria 5, 5e, 6 sau mai mare (max. 100 m), EIA/TIA-568 100Ω STP (max. 100 m)
• Silentios: Fara ventilator
• Disipare termica maxima: 48.39 BTU/h
• Capacitate comutare: 48 Gbps
• Tabela adrese MAC: 8000
• Rata de expediere a pachetelor de date: 35.7 Mpps
• Jumbo Frame: 10 KB
• Calitatea serviciului: Suporta prioritate Port-based/802.1p/DSCP, Suporta 4 cozi prioritare, Rate Limit, Storm Control
• Caracteristici L2: IGMP Snooping V1/V2/V3, Static Link Aggregation, Port Mirroring, Cable Diagnostics, Loop Prevention
• VLAN: Suporta simultan pana la 32 de VLAN-uri (din 4k de ID-uri VLAN), MTU/Port/Tag VLAN
• Metoda de transmisie: Store-and-Forward
• Montak: Desktop & Rack
• Consum energie: 14.19 W
• Alimentare: 100-240 VAC (50/60 Hz)
• Dimensiuni: 294 x 180 x 44 mm
• Temperatura de functionare: 0°C – +40°C
• Umiditate: 10 % – 90 % RH
