| Specificatii Tehnice | |
|---|---|
| Caracteristici Hardware | |
| Standarde si Protocoale | • IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q, IEEE802.3bz • TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP, WireGuard VPN |
| Interfata | • 1× Port RJ45 WAN 2.5G • 1× Port RJ45 WAN/LAN 2.5G • 1× Port Gigabit SFP WAN/LAN • 4× Porturi Gigabit RJ45 WAN/LAN • 1× Port USB 2.0 (Suporta stocare USB si backup LTE cu dongle LTE) |
| Retea Media | • 10BASE-T: Cablu UTP categorie 3, 4, 5 (Max 100 m) • 100BASE-TX: Cablu UTP categorie 5, 5e (Max 100 m) • 1000BASE-T: Cablu UTP categorie 5, 5e, 6 (Max 100 m) • 2500BASE-T: Cablu UTP categorie 5, 5e, 6 (Max 100 m) |
| Numar Ventilatoare | Fara ventilator |
| Butoane | Buton de resetare |
| Alimentator | Adaptor 12V/1.5A |
| Buget PoE | – |
| Flash | 128MB NAND |
| DRAM | 1 GB DDR4 |
| LED-uri | PWR, SYS, SFP, USB, WAN (Viteza, Link/Act), LAN (Viteza, Link/Act) |
| Dimensiuni | 226 × 131 × 35 mm |
| Protectie | Protectie impotriva fluctuatiilor de 4 kV |
| Protectie Atacuri | • Aparare impotriva floodului TCP/UDP/ICMP • Blocare scanare TCP (FIN/Xmas/Null) • Blocare Ping de la WAN |
| Carcasa | Otel |
| Montaj | Desktop/Montare pe perete |
| Consum Maxim | 14.2 W (cu USB2.0 conectat) 7.1 W (fara USB2.0 conectat) |
| Performanta | |
| Sesiuni Concomitente | 500,000 |
| New Sessions/Second | 6,000 |
| NAT (IP Static) | 2365.17 Mbps / 2364.45 Mbps |
| NAT (DHCP) | 2364.45 Mbps / 2366.04 Mbps |
| NAT (PPPoE) | 2347.14 Mbps / 2348.29 Mbps |
| NAT (L2TP) | 1308.86 Mbps / 974.10 Mbps |
| NAT (PPTP) | 1236.27 Mbps / 1280.99 Mbps |
| IPsec VPN Throughput | • ESP-SHA1-AES256: 673.3 Mbps • ESP-SHA256-AES256: 650.2 Mbps • ESP-SHA384-AES256: 629.3 Mbps • ESP-SHA512-AES256: 633.8 Mbps |
| L2TP VPN Throughput | • Necriptat: 1243.7 Mbps • Criptat: 561.0 Mbps |
| SSL VPN Throughput | 132.24 Mbps |
| 66 Byte Packet Forwarding Rate | 1832.69 Mbps / 1741.84 Mbps |
| 1,518 Byte Packet Forwarding Rate | 2461.18 Mbps / 2457.32 Mbps |
| Functii de Baza | |
| Tip Conexiune WAN | • IPv4_Static IP • IPv4_Dynamic IP • IPv4_PPPOE • IPv4_L2TP • IPv4_PPTP • IPv6_PPP • IPv6_DHCPv6 • IPv6_Static IP • IPv6_6in4 • IPv6_Pass-Through • Mobile Broadband: modem 4G/3G pentru backup prin port USB |
| Clonare MAC | Modificare adresa MAC WAN/LAN |
| DHCP | • Server DHCP • Server DHCPv6 PD (doar in modul autonom) • Personalizare optiuni DHCP • Rezervare adresa DHCP • Interfete multi-IP • DHCP multi-net |
| IPv6 | Static IP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Mod neadresabil |
| VLAN | 802.1Q VLAN |
| IPTV | Proxy IGMP v2/v3, Mod personalizat, Mod punte |
| Functii Avansate | |
| Routing Avansat | • Rutare statica • Rutare bazata pe politica • RIP (doar in modul autonom) • OSPF (doar in modul autonom) |
| Control Latime de Banda | • Control latime de banda bazat pe IP/Port • Garantare si limitare a latimii de banda |
| Echilibrarea Traficului | • Echilibrare incarcatura inteligenta • Rutare optimizata pentru aplicatii • Backup link (Timing§, Failover) • Detectare online |
| NAT | • NAT unu la unu • NAT multi-net • Redirectionare port • Declansare porturi • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnP |
| Limita Sesiuni | Limita sesiuni bazata pe IP |
| VPN | |
| VPN IPsec | • 100 Tuneluri VPN IPsec • LAN-to-LAN, Client-to-LAN • Mod Negociere Principal, Agresiv • Algoritmi de Criptare DES, 3DES, SHA1, AES128, AES192, AES256 • IKEv1/v2 • Algoritmi de Autentificare MD5, SHA1, SHA2-384 si SHA2-512 • Traversare NAT (NAT-T) • Detectare Peer Mort (DPD) • Secretizare inaintata Perfect Forward (PFS) |
| VPN PPTP | • Server VPN PPTP • Clienti VPN PPTP (12) • 60 Tuneluri (Partajat cu L2TP) • PPTP cu Criptare MPPE |
| VPN L2TP | • Server VPN L2TP • Clienti VPN L2TP (12) • 60 Tuneluri (Partajat cu PPTP) • L2TP peste IPSec |
| OpenVPN | • Server OpenVPN • Clienti OpenVPN (6) • 66 Tuneluri OpenVPN* |
| Autentificare | |
| Autentificare Web | • Fara autentificare • Parola simpla • Hotspot (Utilizator Local/Voucher*/SMS*/Radius*) • Server RADIUS Extern • Server Portal Extern* • LDAP |
| Management | |
| Aplicatie Omada | Da. Necesita utilizarea controlerului bazat pe Cloud OC300, OC200, Omada Cloud-Based sau controlerul software Omada. |
| Management Centralizat | • Controler bazat pe cloud Omada • Controler hardware Omada (OC300) • Controler hardware Omada (OC200) • Controler software Omada |
| Acces prin Cloud | Da. Necesita utilizarea controlerului bazat pe cloud OC300, OC200, Omada Cloud-Based sau controlerul software Omada. |
| Servicii | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe) |
| Mentenanta | • Interfata de management web • Management la distanta • Exportare si importare configurare • SNMP v1/v2c/v3* • Diagnostica (Ping & Traceroute)§ • Sincronizare NTP§ • Port Mirroring • CLI (doar in modul autonom) • Suport syslog |
| Provizionare Zero-Touch | Da. Necesita utilizarea controlerului bazat pe nor Omada. |
| Functii de Management | • Descoperire automata a dispozitivelor • Monitorizare inteligenta a retelei • Avertismente evenimente anormale • Configurare unificata • Programare repornire • Configurare portal captiv • ZTP (Provizionare Zero-Touch) |
| Altele | |
| Certificari | CE, FCC, RoHS |
| Cerinte de Sistem | Microsoft Windows 98SE, NT, 2000, XP, Vista™ sau Windows 7/8/8.1/10, MAC OS, NetWare, UNIX sau Linux |
| Temperatura de operare | 0–40 ℃ |
