| Caracteristici Hardware | |
|---|---|
| Standarde si protocoale: |
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x |
| Interfata: | 1× 10/100/1000 Mbps RJ45 PoE In Ports (compliance with 802.3af/at/bt) 4× 10/100/1000 Mbps RJ45 PoE Out Ports (compliance with 802.3af/at PoE) |
| Retea medie: | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) |
| Numar ventilatoare: | Fara (fanless) |
| Alimentare: | PoE 802.3af/at/bt |
| Porturi (RJ45) PoE: |
Port PoE IN 5, in conformitate cu 802.3af/at/bt Port PoE OUT: 1-4, in conformitate cu 802.3af/at PoE Buget PoE: 64 W cand este alimentat 802.3bt Type 4 (90 W) 44 W cand este alimentat 802.3bt Type 3 (60 W) 19 W cand este alimentat 802.3at 6W cand este alimentata 802.3af |
| Dimensiuni: | 100 x 38.5 x 170 mm |
| Consum: | max. 71.5 W (cand este alimentat 802.3bt Type 4 (90 W)) |
| Performanta | |
| Capacitate switching: | 10 Gbps |
| Packet Forwarding Rate: | 7.44 Mpps |
| Numar adrese MAC: | 8K |
| Jumbo Frame: | 9 Kb |
| Caracteristici software | |
| Calitatea Serviciului: |
802.1p CoS/DSCP priority 8 priority queues Priority Schedule Mode – SP (Strict Priority) – WRR (Weighted Round Robin) Queue Weight Config Bandwidth Control – Port/Flow-based Rating Limit Smoother Performance Storm Control – Multiple Control Modes(kbps/ratio) – Broadcast/Multicast/Unknown-Unicast Control |
| Caracteristici L2 si L2+: |
Interfete IP 32 – Support IPv4/IPv6 Interface Static Routing – 32 IPv4/IPv6 Static Routes DHCP Server DHCP Relay – DHCP Interface Relay – DHCP VLAN Relay DHCP L2 Relay Static ARP Proxy ARP Gratuitous ARP Link Aggregation – Static link aggregation – 802.3ad LACP – Up to 8 aggregation groups and up to 8 ports per group Spanning Tree Protocol – 802.1D STP – 802.1w RSTP – 802.1s MSTP – STP Security: TC Protect, BPDU Filter/Protect, Root Protect Loopback Detection Flow Control – 802.3x Flow Control Mirroring – Port Mirroring – CPU Mirroring – One-to-One – Many-to-One – Flow-Based – Ingress/Egress/Both Device Link Detect Protocol (DLDP) 802.1ab LLDP/ LLDP-MED |
| L2 Multicast: |
511 IPv4, IPv6 shared multicast groups IGMP Snooping – IGMP v1/v2/v3 Snooping – Fast Leave – IGMP Snooping Querier – Static Group Config Multicast VLAN Registration (MVR) Multicast Filtering MLD Snooping – MLD v1/v2 Snooping – Fast Leave – MLD Snooping Querier – Static Group Config Limited IP Multicast (256 profiles and 16 entries per profile) |
| Caracteristici Avansate: |
Automatic Device Discovery Batch Configuration Batch Firmware Upgrading Intelligent Network Monitoring Abnormal Event Warnings Unified Configuration Reboot Schedule |
| IPv6 Support: |
IPv6 Dual IPv4/IPv6 Multicast Listener Discovery (MLD) Snooping IPv6 neighbor discovery (ND) Path maximum transmission unit (MTU) discovery Internet Control Message Protocol (ICMP) version 6 TCPv6/UDPv6 IPv6 applications – DHCPv6 Client – Ping6 – Tracert6 – Telnet (v6) – IPv6 SNMP – IPv6 SSH – IPv6 SSL – Http/Https – IPv6 TFTP |
| VLAN: |
VLAN Group – Max. 4K VLAN Groups 802.1Q tag VLAN MAC VLAN: 12 Entries Protocol VLAN GVRP Voice VLAN |
| Lista control acces: |
Suporta pana la 230 intrari Time-Range – Time Slice – Week Time-Range – Absolute Time-Range – Holiday Time-based ACL MAC ACL – Source MAC – Destination MAC – VLAN ID – User Priority – Ether Type IP ACL – Source IP – Destination IP – IP Protocol – TCP Flag – TCP/UDP Source Port – TCP/UDP Destination Port – DSCP/IP TOS IPv6 ACL Combined ACL Rule Operation – Permit/Deny Policy Action – Mirror – Rate Limit – Redirect – QoS Remark ACL Rules Binding – Port Binding – VLAN Binding Actions for flows – Mirror (to supported interface) – Redirect (to supported interface) – Rate Limit – QoS Remark |
| Securitate: |
AAA 802.1X – Port-based authentication – MAC (Host) based authentication – Authentication Method includes PAP/EAP-MD5 – MAB – Guest VLAN – Support Radius authentication and accountability IP/IPv6-MAC Binding – 512 Binding Entries – DHCP Snooping – DHCPv6 Snooping – ARP Inspection – ND Detection IP Source Guard – 253 Entries – Source IP+Source MAC • IPv6 Source Guard – 183 Entries – Source IPv6 Address+Source MAC DoS Defend Static/Dynamic/Permanent Port Security – Up to 64 MAC addresses per port Broadcast/Multicast/Unicast Storm Control – kbps/ratio control mode Port Isolation Secure web management through HTTPS with SSLv3/TLS 1.2 Secure Command Line Interface (CLI) management with SSHv1/SSHv2 IP/Port/MAC-based access control |
| MIBs: |
MIB II (RFC1213) Bridge MIB (RFC1493) P/Q-Bridge MIB (RFC2674) Radius Accounting Client MIB (RFC2620) Radius Authentication Client MIB (RFC2618) Remote Ping, Traceroute MIB (RFC2925) Support TP-Link private MIBs RMON MIB(RFC1757, rmon 1,2,3,9) |
| Management | |
| Aplicatia Omanda: |
Da Omada Cloud-Based Controller Omada Hardware Controller Omada Software Controller |
| Management centralizat: |
Omada Cloud-Based Controller Omada Hardware Controller Omada Software Controller |
| Acces Cloud: |
Da Omada Cloud-Based Controller Omada Hardware Controller Omada Software Controller |
| Functii management: |
Web-based GUI Command Line Interface (CLI) through telnet SNMPv1/v2c/v3 SNMP Trap/Inform RMON (1,2,3,9 groups) SDM Template DHCP/BOOTP Client Dual Image, Dual Configuration CPU Monitoring Cable Diagnostics EEE SNTP System Log |
| Caracteristici generale | |
| Temperatura de functionare: | de la -40°C pana la +60°C |
| Grad de protectie: | IP 55 |
| Protectie impotriva trasnetului: | 4KV |
