| Interfata |
- 24× 2.5 Gbps RJ45 Ports
- 4× 10G SFP+ Slots
- 1× RJ45 Console Port
- 1× Micro-USB Console Port
|
| Cantitate Ventilator |
1x |
| Alimentare |
100-240 V AC~50/60 Hz |
| Dimensiuni |
440 × 180 × 44 mm |
| Montaj |
Rack |
| Consum maxim de energie |
45.1 W (110V/60Hz) |
| Disiparea maxima a caldurii |
154.38 BTU/h (110 V/60 Hz) |
| Performanta |
|
| Capacitate de Comutare |
200 Gbps |
| Rata de Transfer de Pachete |
148.80 Mpps |
| Tabel de Adrese MAC |
32 K |
| Memorie Buffer de Pachete |
16 Mbit |
| Jumbo Frame |
9 KB |
| Calitatea Serviciului (QoS) |
- 8 cozi de prioritati
- 802.1p CoS/DSCP prioritate
- Programarea cozilor
- SP (Strict Priority)
- WRR (Weighted Round Robin)
- SP+WRR
- Control al Latimii de Banda
- Control al Ratei bazat pe Port/Flow
- Performanta Mai Lina
- Actiuni pentru Fluxuri
- Mirror (pe interfata suportata)
- Redirect (pe interfata suportata)
- Limitare a Ratei
- Observatii QoS
|
| Caracteristici Layer 3 |
- 32 Interfete IPv4/IPv6
- Rutare Statica
- ARP Static
- ARP Proxy
- ARP Gratuit
- Server DHCP
- Releu DHCP
- Releu Interfata DHCP
- Releu VLAN DHCP
- Releu L2 DHCP
|
| Link Aggregation |
- Agregare de Linkuri
- Agregare statica a linkurilor
- 802.3ad LACP
- Pâna la 8 grupuri de agregare, continând 8 porturi per grup
|
| Spanning Tree Protocol |
- 802.1d STP
- 802.1w RSTP
- 802.1s MSTP
- Securitate STP: TC Protect, Filtru BPDU, Protectie Root
|
| Detectie de Bucla inchisa |
- Bazata pe port
- Bazata pe VLAN
|
| Control al Fluxului |
- Control al Fluxului 802.3x
- Prevenirea Blocarii HOL
|
| Reflectie (Mirroring) |
- Reflectie Port
- Reflectie CPU
- De la Unul la Unul
- De la Multiplu la Unul
- Tx/Rx/Ambele
|
| Multicast L2 |
- Monitorizare IGMP
- Monitorizare IGMP v1/v2/v3
- Leave Rapid
- Interogare IGMP Snooping
- Autentificare IGMP
- Monitorizare MLD
- Monitorizare MLD v1/v2
- Leave Rapid
- Interogare MLD Snooping
- Configuratie Grup Static
- Multicast IP Limitat
- MVR
- Filtrare Multicast: 256 profile si 16 intrari per profil
|
| Caracteristici Avansate |
- Descoperire Automata a Dispozitivelor
- Configurare în Masa
- Actualizare în Masa a Firmware-ului
- Monitorizare Inteligenta a Retelei
- Avertizari de Evenimente Anormale
- Configurare Unificata
- Programare Restart
|
| VLAN |
- Grup VLAN
- VLAN 802.1Q Etichetat
- VLAN MAC: 256 Intrari
- VLAN Protocol: Sablon de Protocol 16, VLAN Protocol 16
- GVRP
- VLAN VPN (QinQ)
- Port-Based QinQ
- QinQ Selectiv
- Voice VLAN
|
| Lista de Control al Accesului (ACL) |
- ACL bazata pe timp
- ACL MAC
- MAC sursa
- MAC destinatie
- ID VLAN
- Prioritate Utilizator
- Tip Ether
- ACL IP
- IP sursa
- IP destinatie
- Fragment
- Protocol IP
- Flag TCP
- Port TCP/UDP
- DSCP/IP TOS
- Prioritate Utilizator
- ACL Combinata
- ACL Continut Pachet
- ACL IPv6
- Politici
- Reflectie (Mirroring)
- Redirectionare (Redirect)
- Limitare Rata
- QoS Remark
- Aplicare ACL la Port/VLAN
|
| Securitate |
- Legare IP-MAC-Port
- Snooping DHCP
- Inspectare ARP
- Protectie IPv4 Source Guard: 100 Intrari
- Legare IPv6-MAC-Port
- Snooping DHCPv6
- Detectare ND
- Protectie IPv6 Source Guard: 100 Intrari
- Aparare DoS
- Securitate Port Statica/Dinamica
- Pâna la 64 de adrese MAC pe port
- Control Broadcast/Multicast/Unicast Storm
- Mod de control kbps/ratio
- 802.1X
- Autentificare bazata pe Port
- Autentificare bazata pe MAC
- Atribuire VLAN
- MAB
- VLAN Oaspeti
- Autentificare si responsabilitate Radius
- AAA (inclusiv TACACS+)
- Isolare Port
- Management Web Securizat prin HTTPS cu SSLv3/TLS 1.2
- Management Interfata de Linie de Comanda Securizata (CLI) cu SSHv1/SSHv2
- Control bazat pe IP/Port/MAC
|
| IPv6 |
- Dual IPv4/IPv6
- MLD (Multicast Listener Discovery) Snooping
- ACL IPv6
- Interfata IPv6
- Routing IPv6 Static
- Descoperirea vecinilor IPv6 (ND)
- Descoperirea MTU maxima a traseului (MTU)
- Protocolul de mesaje de control Internet IPv6 (ICMPv6)
- TCPv6/UDPv6
- Aplicatii IPv6
- Client DHCPv6
- Ping6
- Tracert6
- Telnet (v6)
- SNMP IPv6
- SSH IPv6
- SSL IPv6
- Http/Https IPv6
- TFTP IPv6
|
| MIBs |
- MIB II (RFC1213)
- Interfata MIB (RFC2233)
- Interfata Ethernet MIB (RFC1643)
- Bridge MIB (RFC1493)
- P/Q-Bridge MIB (RFC2674)
- RMON MIB (RFC2819)
- RMON2 MIB (RFC2021)
- Radius Accounting Client MIB (RFC2620)
- Radius Authentication Client MIB (RFC2618)
- Remote Ping, Traceroute MIB (RFC2925)
- Support TP-Link private MIB
|
| Omada App |
Da. Necesita folosirea OC300, OC200, Omada Cloud-Based Controller, sau Omada Software Controller. |
| Centralized Management |
- Omada Cloud-Based Controller
- Omada Hardware Controller (OC300)
- Omada Hardware Controller (OC200)
- Omada Software Controller
|
| Cloud Access |
Da. Necesita folosirea OC300, OC200, Omada Cloud-Based Controller, sau Omada Software Controller. |
| Zero-Touch Provisioning |
Da. Necesita Omada Cloud-Based Controller. |
| Caracteristici administrare |
- Web-based GUI
- Command Line Interface (CLI) prin portul consolei, telnet
- SNMP v1/v2c/v3
- Trap/Inform
- RMON (1,2,3,9 groups)
- SDM Template
- DHCP/BOOTP Client
- 802.1ab LLDP/LLDP-MED
- DHCP AutoInstall
- Dual Image, Dual Configuration
- CPU Monitoring
- Cable Diagnostics
- EEE
- Password Recovery
- SNTP
- System Log
|
| Altele |
- Certification: CE, FCC, RoHS
- Sistem necesar:
- Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.
- Environment:
- Temperatura operare: 0–40 ℃ (32–104 ℉);
- Umiditate: 10–90% RH fara condensare
|
