24x porturi RJ45 (10/100/1000 Mbps)

4x slot-uri Gigabit SFP

1x port consola RJ45

1x port micro-USB

8 priority queues

prioritate 802.1p CoS/DSCP

programare coada

SP (prioritate stricta)

WRR (Weighted Round Robin)

SP + WRR

control latime de banda

port/flow bazat pe limitare rata

performanta lina

actiuni pentru fluxuri

mirror

redirect

limitare rata

QoS remark

link aggregation

agragare link static

802.3ad LACP

pana la 8 grupuri de agregare, 8 porturi/grup

Spanning Tree Protocol (802.1d STP; 802.1w RSTP; 802.1s MSTP; STP Security: TC Protect, BPDU Filter, Root Protect)

Detectie Loopback (port based, VLAN based)

Control flux (control flux 802.3x, prevenire blocare HOL)

Mirroring (Port Mirroring; CPU Mirroring; One-to-One; Many-to-One; Tx/Rx/Both)

Grup-uri IGMP 511 (IPv4, IPv6)

IGMP Snooping (IGMP v1/v2/v3 Snooping; Fast Leave; IGMP Snooping Querier; IGMP Authentication)

Autentificare IGMP

MLD Snooping (MLD v1/v2 Snooping; Fast Leave; MLD Snooping Querier; Static Group Config; Limited IP Multicast)

MVR

Filtrare Multicast (256 profile si 16 intrari / profil)

Grup VLAN (Max 4K grupuri VLAN)

802.1Q Tagged VLAN

MAC VLAN: 12 intrari

Protocol VLAN: Protocol Template 16, Protocol VLAN 16

VLAN privat

GVRP

VLAN VPN (QinQ)

Port-Based (QinQ)

Selective (QinQ)

Voice VLAN

Time-based ACL

MAC ACL (Source MAC; Destination MAC; VLAN ID; User Priority; Ether Type)

IP ACL (Source IP; Destination IP; Fragment; IP Protocol; TCP Flag; TCP/UDP Port; DSCP/IP TOS; User Priority)

Combined ACL

Packet Content ACL

IPv6 ACL

Policy (Mirroring, Redirect, Rate Limit, QoS Remark)

ACL aplicat la Port/VLAN

IP-MAC port binding (DHCP Snooping, inspectie ARP, protectie sursa IPv6)

IPv6-MAC port binding (DHCPv6 Snooping, detectare ND, protectie sursa IPv6)

DoS Defend

Securitate port static/dynamic (pana la 64 adrese MAC pe port)

Broadcast/Multicast/Unicast Storm Control (kbps/report/pps mod control/IP/Port/MAC control acces)

802.1X (autentificare port, autentificare MAC – Asignare VLAN, MAB, VLAN guest, radius si autentificare raspundere

AAA (TACACS+)

Izolare port

Administrare Web securizata HTTPS cu SSLv3/TLS 1.2

Management interfata linie de comanda cu SSHv1/SSHv2

IP/Port/MAC bazat pe control acces

IPv6 Dual IPv4/IPv6

Multicast Listener Discovery (MLD) Snooping

IPv6 ACL

Interfata IPv6

Rutare statica IPv6

IPv6 neighbor discovery (ND)

Path maximum transmission unit (MTU) discovery

Internet Control Message Protocol (ICMP) version 6

TCPv6/UDPv6

Aplicatii IPv6 (DHCPv6 Client, Ping6, Tracert6, Telnet (v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/Https, IPv6 TFTP)

16 interfete IPv4/IPv6

rutare statica (48 rute statice)

static ARP (316 intrari statice)

Proxy ARP

ARP gratuit

DHCP Server

Releu DHCP (interfata releu DHCP, releu VLAN DHCP, releu VLAN DHCP)

Releu L2 DHCP

Web-based GUI

Command Line Interface (CLI) through the console port, telnet

SNMP v1/v2c/v3 (Trap/Inform, RMON (1,2,3,9 groups)

SDM Template

DHCP/BOOTP Client

802.1ab LLDP/LLDP-MED

DHCP AutoInstall

Dual Image, Configurare Duala

CPU Monitoring

Diagnosticare cablu

EEE

Recuperare parola

SNTP

Logare sistem

Suporta Omada Hardware Controller (OC200/OC300), Software Controller, Cloud-Based Controller

Descoperire automata dispozitiv

Batch Configuration

Batch Firmware Upgrading

Monitorizare inteligenta a retelei

Avertizare evenimente anormale

Configurare Unified

Programare Reboot

ZTP

MIB II (RFC1213)

Interfata MIB (RFC2233)

Interfata Ethernet MIB (RFC1643)

Bridge MIB (RFC1493)

P/Q-Bridge MIB (RFC2674)

RMON MIB (RFC2819)

RMON2 MIB (RFC2021)

Radius Accounting Client MIB (RFC2620)

Radius Authentication Client MIB (RFC2618)

Remote Ping, Traceroute MIB (RFC2925)

Support TP-Link private MIB
