Descriere
| Senzor: | 1/2.8 inch CMOS |
| Rezolutie: | 2 MP (1920 x 1080 pixeli) |
| Lentila varifocala: | 4.8 – 120 mm |
| Diafragma: | F1.6 – F3.5 |
| Viteza shutter electronic: | 1/3 – 1/30000 s |
| Unghi de vizualizare: | 60.6° – 3.2° (Orizontal) / 34.1° – 1.8° (Vertical) / 69.4° – 3.7° (Diagonal) |
| Sistem scanare: | Progresiv |
| Iluminare minima: | 0.005 lux@F1.6 (Color, 30 IRE), 0.0005 lux@F1.6 (B/W, 30 IRE), 0 lux (IR light) |
| RAM: | 256 MB |
| ROM: | 128 MB |
| Distanta IR: | 150 m |
| Control iluminare: | Zoom Prio, manual |
| Zoom optic: | 25 x |
| Zoom digital: | 16 x |
| Control focus: | Auto, semi-auto, manual |
| Distanta DORI: | Detectie: 1655.2 m |
| Observare: 653.8 m | |
| Recunoastere: 331.0 m | |
| Identificare: 165.5 m | |
| PTZ: | Pan: 0° – 360° |
| Tilt: -15° – 90° | |
| Viteza PTZ: | Pan: 0.1° – 200° / s |
| Tilt: 0.1° – 120° / s | |
| Presetari: | 300 |
| Tururi: | 8 (pana la 32 presetari / tur) |
| Sablon: | 5 |
| Scanare: | 5 |
| Memorie power-off: | Da |
| Protocol PTZ: | DH-SD, Pelco-P/D (Auto recognition) |
| Rezolutii inregistrare: | 1080p (1920 × 1080), 720p (1280 × 720), D1 (704 ×576 / 704 × 480) |
| Cadre/secunda: | 1080p (25/30 fps), 720p (25/30/50/60 fps) |
| Functii: | Day / Night, BLC, WDR, HLC, 2DNR, 3DNR, Zoom digital, zoom optic, TVI, CVI, CVBS, AHD |
| BNC: | 1 |
| RS-485: | 1 |
| Intrare audio: | 1 |
| Intrari alarma: | 2 |
| Iesiri alarma: | 1 |
| Alimentare: | 12 VDC, 3 A |
| Protectii: | IP66, protectie la trasnet TVS 6000V, protectie la supratensiune, protectie la fluctuatii de tensiune |
| Temperatura de functionare: | -40°C – 70°C |
| Dimensiuni: | 310.0 mm × Φ185.7 mm |
| Greutate: | 3.9 Kg |
