| Senzor: |
1/2.8 inch Progressive Scan CMOS |
| Rezolutie video: |
4 MP (2560 x 1440 pixeli) |
| Lentila fixa: |
2.8 mm |
| Unghi de vizualizare: |
104° (orizontal) / 57° (vertical) / 123° (diagonal) |
| Iluminare minima: |
Color: 0.01 Lux @ (F2.2, AGC ON),B/W: 0 Lux with IR |
| Viteza shutter: |
1/3 – 1/100000 s |
| Zi & noapte: |
IR cut filter |
| Distanta IR: |
20 m |
| Distanta DORI: |
Detectie: 53 m |
|
Observare: 21 m |
|
Recunoastere: 10 m |
|
Identificare: 5 m |
| Functii: |
Smart Supplement Light, DWDR, SNR, privacy mask, BLC, HLC, 3D DNR, Detectie miscare, exceptii |
| Comutator zi / noapte: |
Zi / noapte / auto / programat |
| Cadre / secunda: |
20 – 25 FPS |
| Compresie video: |
H.265+/H.265/H.264+/H.264/MJPEG |
| Bit Rate video: |
32 Kbps – 8 Mbps |
| Control Bit Rate: |
CBR, VBR |
| Securitate: |
Password protection, complicated password, watermark, basic and digest authentication for HTTP, security audit log, host authentication (MAC address) |
| Vizualizare Live simultana: |
Pana la 6 canale |
| API: |
ONVIF (Profile S, Profile T), ISAPI, SDK |
| Protocoale: |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv4, IPv6, UDP, QoS, SNMP, DDNS |
| Numar utilizatori: |
Pana la 32 pe 3 nivele (admin, operator, utilizator) |
| Software: |
iVMS-4200 |
| Port retea: |
1 x RJ45 10/100 Mbps self-adaptive |
| Alimentare: |
12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug, reverse polarity protection |
|
PoE IEEE802.3af, Class 0, max. 6.5 W |
| Grad de protectie: |
IP67 |
| Material: |
Plastic |
| Temperaturi de functionare: |
-30°C – 45°C |
| Dimensiuni: |
Ø112 x 88.4 mm |
| Greutate: |
325 g |
