Senzor:
|
1/2.8 inch Progressive Scan CMOS
|
|
Rezolutie video:
|
4 MP (2560 x 1440 pixeli)
|
|
Lentila fixa:
|
2.8 mm
|
|
Unghi de vizualizare:
|
104° (orizontal) / 57° (vertical) / 123° (diagonal)
|
|
Iluminare minima:
|
Color: 0.01 Lux @ (F2.2, AGC ON),B/W: 0 Lux with IR
|
|
Viteza shutter:
|
1/3 – 1/100000 s
|
|
Zi & noapte:
|
IR cut filter
|
|
Distanta IR:
|
20 m
|
|
Distanta DORI:
|
Detectie: 53 m
|
|
|
Observare: 21 m
|
|
|
Recunoastere: 10 m
|
|
|
Identificare: 5 m
|
|
Functii:
|
Smart Supplement Light, DWDR, SNR, privacy mask, BLC, HLC, 3D DNR, Detectie miscare, exceptii
|
|
Comutator zi / noapte:
|
Zi / noapte / auto / programat
|
|
Cadre / secunda:
|
20 – 25 FPS
|
|
Compresie video:
|
H.265+/H.265/H.264+/H.264/MJPEG
|
|
Bit Rate video:
|
32 Kbps – 8 Mbps
|
|
Control Bit Rate:
|
CBR, VBR
|
|
Securitate:
|
Password protection, complicated password, watermark, basic and digest authentication for HTTP, security audit log, host authentication (MAC address)
|
|
Vizualizare Live simultana:
|
Pana la 6 canale
|
|
API:
|
ONVIF (Profile S, Profile T), ISAPI, SDK
|
|
Protocoale:
|
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv4, IPv6, UDP, QoS, SNMP, DDNS
|
|
Numar utilizatori:
|
Pana la 32 pe 3 nivele (admin, operator, utilizator)
|
|
Software:
|
iVMS-4200
|
|
Port retea:
|
1 x RJ45 10/100 Mbps self-adaptive
|
|
Alimentare:
|
12 VDC ± 25%, 0.4 A, max. 4.8 W, Ø5.5 mm coaxial power plug, reverse polarity protection
|
|
|
PoE IEEE802.3af, Class 0, max. 6.5 W
|
|
Material:
|
Plastic
|
|
Temperaturi de functionare:
|
-10°C – 40°C
|
|
Dimensiuni:
|
Ø110.8 x 85.2 mm
|
|
Greutate:
|
240 g
|
