| Senzor: |
1/3 inch Progressive scan CMOS |
| Rezolutie: |
4 MP (2560 × 1440 pixeli) |
| Lentila fixa: |
2.8 mm |
| Diafragma: |
F1.6 |
| Unghi de vizualizare: |
98° (orizontal) / 54° (vertical) / 114° (diagonal) |
| Iluminare minima: |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Viteza shutter: |
1/3 – 1/100000 s |
| Zi/Noapte: |
IR Cut filter |
| Distanta DORI: |
Detectie: 63 m |
|
Observare: 25 m |
|
Recunoastere: 12 m |
|
Identificare: 6 m |
| Distanta IR: |
30 m |
| Distana lumina alba: |
30 m |
| Cadre / secunda: |
20-25 FPS |
| Compresie video: |
H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Bit rate: |
32 Kbps – 8 Mbps |
| Control Bit Rate: |
CBR, VBR |
| Functii: |
ROI, BLC, 3D DNR, HLC, Detectia miscarii, alarma manipulare video, exceptii |
| Tip audio: |
Mono |
| Compresie audio: |
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Bit rate audio: |
64 Kbps (G.711 ulaw/G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) |
| Protocoale retea: |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
| Vizualizare simultana: |
Pana la 6 canale |
| API: |
Open Network Video Interface (Profile S, Profile T), ISAPI, SDK |
| Securitate: |
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) |
| Numar de utilizatori: |
Pana la 32 pe 3 nivele (administrator, operator, utilizator) |
| Software compatibil: |
iVMS-4200, HiLookVision |
| Browsere compatibile: |
Internet Explorer, Google Chrome, Mozilla Firefox, Microsoft Edge |
| Interfata: |
1 x RJ45 10/100 M self-adaptive |
| Microfon: |
Incorporat |
| Alimentare: |
12 VDC ± 25%, 0.5 A, max. 6 W, Ø 5.5 mm coaxial power plug, reverse polarity protection |
|
PoE: IEEE 802.3af, Class 3, max. 7.5 W |
| Material: |
Metal + Plastic |
| Temperatura de functionare: |
– 30°C – 60°C |
| Grad de protectie: |
IP67, IK08 |
| Dimensiuni: |
Ø121.4 x 97.7mm |
| Greutate: |
550 g |
