Senzor:
|
1/2.9 inch Progressive Scan CMOS
|
|
Rezolutie video:
|
2 MP (1920 x 1080 pixeli)
|
|
Lentila fixa:
|
2.8 mm
|
|
Viteza shutter:
|
1/3 – 1/100000 s
|
|
Iluminare minima:
|
Color: 0.01 Lux @ (F2.2, AGC ON), B/W: 0 Lux with IR
|
|
Zi & noapte:
|
IR cut filter
|
|
Unghi de vizualizare:
|
101° orizontal / 56° vertical / 118° diagonal
|
|
Diafragma:
|
F2.2
|
|
Distanta DORI:
|
Detectie: 44 m
|
|
|
Observare: 17 m
|
|
|
Recunoastere: 8 m
|
|
|
Identificare: 4 m
|
|
Distanta IR:
|
20 m
|
|
Distanta lumina alba:
|
15 m
|
|
Functii:
|
Smart supplement light, ROI, Environment noise filtering, DWDR, SNR, Privacy Mask, BLC, HLC, 3D DNR, Detectie miscare, Detectie oameni, Exceptii
|
|
Cadre / secunda:
|
25 – 30 FPS
|
|
Compresie video:
|
H.265+/H.265/H.264+/H.264/MJPEG
|
|
Bit Rate video:
|
32 Kbps – 8 Mbps
|
|
Control bit rate:
|
CBR, VBR
|
|
Compresie audio:
|
G.711ulaw/AAC-LC
|
|
Bit Rate audio:
|
64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC)
|
|
Protocoale:
|
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv4, IPv6, UDP, QoS
|
|
API:
|
Open Network Video Interface (Profile S, Profile T), ISAPI, SDK
|
|
Securitate:
|
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
|
|
Vizualizare live simultana:
|
Pana la 6 canale
|
|
Numar utilizatori:
|
Pana la 32 de utilizatori pe 3 nivele (admin, operator, utilizator)
|
|
Software:
|
iVMS-4200, HiLookVision
|
|
Comutator zi / noapte:
|
Zi, Noapte, Auto, Programat
|
|
Port retea:
|
1 x RJ45 10/100 M self-adaptive
|
|
Microfon:
|
Incorporat
|
|
Alimentare:
|
12 VDC ± 25%, 0.42 A, max. 5 W, Ø 5.5 mm coaxial power plug, reverse polarity protection
|
|
|
PoE: IEEE 802.3af, Class 3, max. 6.5 W
|
|
Material:
|
Metal + Plastic
|
|
Temperatura de functionare:
|
-30°C – 45°C
|
|
Dimensiuni:
|
Ø110 x 102.7 mm
|
|
Greutate:
|
345 g
|
